Wharfedale MP1800 Power Amplifier 2x400W @ 4Ohm / 2x260W @ 8Ohm. The steel casing and sturdy construction are only the beginning. Internally MP amps uses extremely reliable components and comparatively simple amplification circuitry. This means that should something happen, MP amp is simple to repair.
Over 1/3rd of the internal chassis is taken up with a massive toroidal transformer. This gives an MP amp the power supply stability to function in the most extreme AC conditions. MP amps are also stable down to 2 Ohms. This allows for multiple 8 Ω or 16 Ω speakers to be driven with extreme and constant power.
Features
- 8 Ohm 2 x 300 Watts
- 4 Ohm 2 x 600 Watts
- 2 Ohm 2 x 900 Watts
- 8 Ohm Bridged 1 x 1200 Watts
- 4 Ohm Bridged 1 x 1800 Watts
Specifications
| Model Name | MP 1800 | MP 2800 |
|---|---|---|
| Stereo Power Output | ||
| 8 Ω x 2 | 300 W | 640 W |
| 4 Ω x 2 | 600 W | 950 W |
| 2 Ω x 2 | 900 W | 1300 W |
| Bridged Mono Power Output | ||
| 8 Ω | 1200 W | 1900 W |
| 4 Ω | 1800 W | 2800 W |
| Frequency Response | 5 Hz – 30 KHz | 5 Hz – 30 KHz |
| Topology | Class AB | Class H |
| Inputs | 2 x XLR, 2 x 6.3 mm Jack | 2 x XLR, 2 x 6.3 mm Jack |
| Outputs | 3 x NL4 (speakON compatible) | 3 x NL4 (speakON compatible) |
| Input Sensitivity & impedance | ||
| Sensitivity | +0 dBu (0.775 Vrms) | +0 dBu (0.775 Vrms) |
| Balanced XLR input | 20 KΩ | 20 KΩ |
| Maximum Input Level | 22 dBu (9.7 Vrms) | 22 dBu (9.7 Vrms) |
| Slew Rate | >30 V / us | >40 V / us |
| Crosstalk | <-70 dB | <-70 dB |
| S/N | >100 dB | >100 dB |
| Distortion (1 W) | <0.05% | <0.015% |
| Damping Factor | >300 | >300 |
| Controls | ||
| Front panel | AC Switch, CH A and CH B Gain Knobs | |
| Rear panel | Stereo & Bridge Mode Switch | |
| Protections | Thermal protect, Over-current protect, Output DC protect, Output short protect, Power on/off mute | |
| Indicators | Power, Protect, Bridge, Peak | |
| Cooling | Variable Speed Fan | |
| Dimensions | 132 x 494 x 464 mm | 132 x 494 x 464 mm |
| Net Weight | 23.5 kg / 51.80 lbs | 25 kg / 55 lbs |
| Gross Weight | 25 kg / 55.11 lbs | 27.5 kg / 61 lbs |
