The F-122C ceiling and wall-mounted speaker covers an extremely wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.
FEATURES
- 30 W full range speaker
- Flat front panel
- High power
- Quick and easy installation
- Heat-resistant back can
- Diffusor for wide dispersion of high frequencies
- For medium ceiling height (2 to 4 m)
SPECIFICATIONS
| F-122C | F-2322C | |
|---|---|---|
| Frequency response | 70 Hz – 20 kHz | 70 Hz – 20 kHz |
| Sensitivity (1 W, 1 m) | 90 dB | 90 dB |
| Rated input (100 V) | 30 W | 30 W |
| Tappings (100 V) | 30 / 10 / 3 / 1 W (100 V), 30 / 15 / 5 / 1.5 / 0.5 W (70 V), 8 Ω | 30 / 10 / 3 / 1 W (100 V), 30 / 15 / 5 / 1.5 / 0.5 W (70 V), 8 Ω |
| Rated input (low impedance) | Continuous pink noise: 60 W (8 Ω), Continuous program: 120 W (8 Ω) | Continuous pink noise: 60 W (8 Ω), Continuous program: 120 W (8 Ω) |
| Rated impedance | 8 Ω | 8 Ω |
| Speaker component | 12 cm cone-type | 12 cm cone-type |
| Finish | Steel plate, Fire-resistant ABS resin (resin material grade: UL-94 V-0), cream white (RAL 9001 or equivalent) | Steel plate, Fire-resistant ABS resin (resin material grade: UL-94 V-0), cream white (RAL 9001 or equivalent) |
| Dimensions | 230 x 229 mm (Ø x D) | 230 x 200 mm (Ø x D) |
| Weight | 3.7 kg | 3.7 kg |
