The Sonance DSP 8-130 MKIII Amplifier sets a new standard in multi-zone audio amplification, combining powerful performance, advanced digital signal processing, and professional-grade flexibility. Designed for demanding residential and commercial installations, this 8-channel Class-D amplifier delivers robust power with up to 130 W RMS per channel at 8 Ω and 145 W per channel at 4 Ω, while bridged outputs allow even higher power for subwoofers or specialty zones.
At the core of the unit is high-resolution DSP with a 24-bit/96 kHz DAC, capable of up to 4608 kbps playback, giving installers and integrators unparalleled control over EQ, crossover, and room tuning. Connectivity is comprehensive, with line inputs, loop outputs, IP and IR control, voltage triggers, and an Ethernet port for network-based management.
The amplifier also includes SonARCâ„¢ v2 support for easy remote configuration and speaker-specific presets that help optimize performance based on the unique acoustic characteristics of each room. Built with reliability in mind, it features robust protection circuitry against over-current, overheating, and voltage instability.
Rack-ready and space-saving with a compact 1U chassis, removable feet, and included rack ears, the DSP 8-130 MKIII fits seamlessly into custom AV setups, multi-room audio systems, and professional sound installations.
Whether powering distributed whole-home audio, dedicated listening zones, or commercial environments, this amplifier delivers consistent, high-fidelity sound and installation-friendly features that professional integrators demand.
Features
- High resolution 24 bit/96 kHz processing DAC capable of 4608 KBPS audio playback
- IP and IR controllable via SonARC v2 for the ultimate in installation flexibility
- Powerful, audiophile grade Class-D amplification, rated and certified at 8 and 4 ohms & stable to 2 ohms
- Compact form factor allows for space savings in the equipment rack with ample power to the speakers
- Meets EU power saving standards
- Terminal blocks accept up to 12AWG speaker cable for longer runs and higher performance
- Input/output connectivity for maximum installation flexibility: Line input/loop outputs; IP, IR, audio and voltage triggers; Ethernet jack for network connectivity
- Bridgeable channels for applications when even more power is required
- Certified to meet worldwide safety and FCC standards (TUV to UL standards, CE, RCM, C-Tick, RoHS, WEEE, UKCA)
- Rack ears and removable feet included
- Compatible with optional Sonance Analog, Digital, or Hybrid Input Modules
Specifications
| Specification | Details |
|---|---|
| Model / SKU | 93538 (North America) / 93539 (International) |
| Channels | 8 (4 stereo pairs) |
| Amplifier Class | Class-D |
| Power Output (RMS) @ 8 Ω | 130 W per channel (all channels driven) |
| Power Output (RMS) @ 4 Ω | 145 W per channel (all channels driven) |
| Bridged Power Output | 300 W @ 8 Ω (peak) |
| Frequency Response | 5 Hz – 50 kHz (bandwidth limited) |
| Total Harmonic Distortion (THD) | <0.1 % @ 100 W, 8 Ω / <0.03 % @ 100 W, 4 Ω |
| Input Sensitivity | 100 mV for 1 W @ 8 Ω; 1140 mV for full power @ 8 Ω |
| Input Impedance | ~20 kΩ |
| Signal-to-Noise Ratio | >100 dB (20 Hz-20 kHz, A-weighted) |
| DSP & DAC | 24-bit / 96 kHz with up to 4608 kbps audio playback |
| Control / Connectivity | IP, IR, voltage triggers, line input/loop-through, Ethernet |
| Power Requirements | 100-120 V @ 60 Hz / 220-240 V @ 50 Hz |
| AC Fuse | 15 A (T15AL ~ 250 V) |
| Rack Space | 1U rack-mountable |
| Dimensions (with Feet) | 17.25″ × 2.125″ × 16.8125″ (438 mm × 54 mm × 427 mm) |
| Dimensions (Rack Ears, no feet) | 19″ × 1.75″ × 16.8125″ (482.6 mm × 44.45 mm × 427 mm) |
| Shipping Weight | ~18 lbs (8.2 kg) |
| Protection | Thermal, over-current, short-circuit, voltage protection |
