Description

The ART 732-A MK5 delivers exceptional sound clarity and power in a compact, rugged enclosure. Designed for professionals who demand premium performance, this speaker features a neodymium 3.0” compression driver with a titanium diaphragm, capable of crossing over at just 700 Hz for accurate, detailed high-end reproduction. The 12” woofer delivers tight, distortion-free bass with remarkable linearity, while the 1400W Class-D amplifier provides high headroom and ultra-fast transient response. Built-in DSP handles everything from crossover management and EQ to thermal and peak protection. RCF’s FiRPHASE technology ensures perfect phase alignment, while XBOOST adds impactful low-end depth at the push of a button. Ideal for touring musicians and rental setups, the lightweight polypropylene cabinet is engineered for superior durability and vibration resistance, even at full volume.



Features



  • 131 dB Max SPL

  • 1400 W 2-way peak power (400W HF + 1000W LF)

  • Wide 90° x 60° constant directivity horn

  • 3” Titanium diaphragm compression driver with neodymium magnet

  • 12” woofer with 2.5” voice coil for powerful bass

  • FiRPHASE technology for accurate phase and imaging

  • XBOOST for deepened low-frequency response

  • Advanced DSP processing with protections and soft limiting

  • Lightweight polypropylene cabinet with steel grille and M10 mounting points

  • Excellent for stage, live sound, and professional PA applications



Specifications



Frequency Response 50 Hz ÷ 20000 Hz
Max SPL @ 1m 131 dB
Horizontal Coverage 90°
Vertical Coverage 60°
Compression Driver 1 x 1.4″ neo, 3.0″ v.c (Titanium)
Woofer 1 x 12″, 2.5″ v.c
Input Signal Balanced / Unbalanced
Input Connectors XLR, Jack
Output Connectors XLR
Input Sensitivity -2 dBu / +4 dBu
Mic Input Sensitivity -32 dBu
Crossover Frequency 700 Hz
Protections Thermal, RMS
Limiter Soft Limiter
Controls Volume, Boost, MIC/Line
Total Power 1400 W Peak
High Frequencies Power 400 W Peak
Low Frequencies Power 1000 W Peak
Cooling Convection
Power Connections VDE
Cabinet Material PP Composite
Hardware 2 x M10
Handles 1 on top, 1 on each side
Pole Mount 35 mm insert
Grille Steel
Color Black
Height 637 mm / 25.08 inches
Width 387 mm / 15.24 inches
Depth 363 mm / 14.29 inches
Weight 17.8 kg / 39.24 lbs
Package Height 680 mm / 26.77 inches
Package Width 440 mm / 17.32 inches
Package Depth 420 mm / 16.54 inches
Package Weight 20.6 kg / 45.42 lbs
Safety Compliance CE compliant
