The Kramer HDMI over Twisted Pair Receiver is used to receive HDMI signals sent over a twisted pair cable. Supporting a maximum data rate of up to 1.65Gbps, the receiver supports HDMI v1.4 with 3D, Deep Color, x.v.Color, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, and 3D Pass-through. Converting the twisted pair cable signal back to DVI, the receiver offers a maximum range of up to 330’ (100m) for 1080i or up to 256’ (80m) for 1080p resolutions using the shielded BC-DGKat723 cable.
Features
- Resolution Support – HDMI v1.4
- System Range up to 330′ / 256′
- Supports 3D / Deep Color / x.v.Color
- EDID / 3D PassThru
- Power Connect System
- LED Indicators
- HDTV Compatible
- HDCP Compliant
- 1/4 Rack Space
Specifications
| Input | 1 RJ-45 connector |
| Output | 1 HDMI connector |
| Bandwidth | Supports up to 1.65Gbps bandwidth per graphics channel |
| Compliance With HDMI Standard | Supports HDMI and HDCP |
| Power Source | 12V DC, 250mA |
| Dimensions | 2.4 x 2.1 x 1″ (6.2 x 5.2 x 2.4 cm) |
| Weight | 0.3 lb (0.14 kg) |
Packaging Info
| Package Weight | 1.005 lb |
| Box Dimensions (LxWxH) | 6.3 x 4.75 x 3.45″ |
