Description

The Metamaterial Absorption Technology (MAT™) incorporated into the design absorbs 99% of unwanted rear noise, ensuring pure, natural sound free from distortion.

The speaker’s advanced driver setup includes a 19 mm (0.75 in.) vented aluminum dome high-frequency driver, a 100 mm (4 in.) aluminum cone midrange driver, and dual 165 mm (6.5 in.) hybrid aluminum cone bass drivers. This combination enables a wide frequency range, from 52 Hz to 20 kHz, with bass extending down to 36 Hz in typical room conditions, offering deep and powerful low-end sound. The 3-way design optimally separates the highs, mids, and lows, ensuring exceptional detail and clarity at all frequencies.

Ideal for home theatre use, the Q Series speaker brings both music and movies to life with its rich, immersive sound. It can be easily integrated with other Q Series speakers and KEF subwoofers to create a comprehensive home theatre system that transports you into the heart of the action. With amplifier requirements ranging from 15 to 200 watts, it provides powerful and dynamic audio across a wide range of listening volumes, maintaining clarity and depth.

Features:

  • 3-way closed-box design for accurate frequency separation and exceptional sound quality
  • 12th generation Uni-Q® driver array for consistent sound dispersion and a dynamic soundstage
  • Metamaterial Absorption Technology (MAT™) absorbs 99% of rear noise, ensuring clear, natural sound
  • Wide frequency range of 52 Hz to 20 kHz, with bass response down to 36 Hz
  • 86 dB sensitivity and a maximum output of 109 dB for impactful sound
  • Versatile compatibility with other Q Series speakers and KEF subwoofers for a complete home theatre setup
  • Amplifier compatibility with power requirements from 15 to 200 W

Specification:

FeatureSpecification
DesignThree-way closed box
Driver ArrayUni-Q Driver Array:
 HF: 19 mm (0.75 in.) vented aluminum dome with MAT
 MF: 100 mm (4 in.) aluminum cone
 LF: 2 x 165 mm (6.5 in.) hybrid aluminum cone
Frequency Range (-6dB)52 Hz – 20 kHz
Typical In-Room Bass Response36 Hz
Frequency Response (±3dB)63 Hz – 20 kHz
Crossover Frequencies560 Hz, 2.7 kHz
Amplifier Requirements15 – 200 W
Sensitivity (2.83V/1m)86 dB
Harmonic Distortion (90dB, 1m)<2% 20 Hz and above, <1% 68 Hz – 20 kHz
Maximum Output109 dB
Impedance4 Ω (min. 3.2 Ω)
Weight14.1 kg (31.1 lbs.)
Dimensions (H x W x D)210 x 629 x 303 mm (8.3 x 24.8 x 11.9 in.)
FinishesWalnut
