dBTechnologies DRKE-212 Extension Bar Instruction Manual

The dBTechnologies DRKE-212 Extension Bar is a professional-grade accessory designed specifically to enhance the array configuration flexibility of the DRK-212 flybar system. This rugged extension bar enables both positive and negative angle configurations, making it an ideal solution for complex speaker array installations, especially in large venues and outdoor setups.

Engineered for use with the VIO L212 line array system, the DRKE-212 Extension Bar allows you to modify the angling of your line array, helping achieve optimal sound dispersion across various audience areas. The package includes one extension bar and four snap pins, which are used to securely fasten the extension to the flybar. The system is designed to integrate seamlessly with dBTechnologies’ rigging hardware and follows strict safety guidelines to ensure stability during operation.

To use the DRKE-212 safely, installation must be carried out by qualified personnel and in accordance with the safety regulations applicable in your country. For configuring array angles, users should consult dBTechnologies’ official configuration software or the Easy Focus tool available on their website under the Software & Controller section.

According to EUROCODE 3 (EN 1993-1-1), the DRKE-212 extension bar can support up to 16 VIO L212 loudspeakers when used with the DRK-212 flybar. For installations following BGV-C1 standards, the maximum allowable load is half. Always verify maximum load capacities using the configuration software before installation.

This reliable and robust extension bar adds significant flexibility to your line array configuration while maintaining high safety standards.

Features:

• Enables positive and negative angle configurations

• Designed for use with DRK-212 flybar and VIO L212 line arrays

• Includes four snap pins for secure attachment

• Supports up to 16 VIO L212 speakers (EUROCODE 3 standard)

• Compatible with dBTechnologies configuration software

• Durable and road-ready construction

• Easy to install and adjust

Specifications:
