The VIO X206 redefines compact professional audio performance by delivering high SPL and exceptional clarity in a slim, highly adaptable enclosure. Designed for both touring and installation applications, it offers the flexibility of being used as a point-source speaker or a line-array module, making it a perfect complement to larger VIO PA systems or as a powerful standalone unit.
Equipped with dual 6.5” neodymium LF transducers and a 1” compression driver, the VIO X206 ensures precise sound reproduction across its frequency range. The system is available in two versions: the standard VIO X206 with a 90° x 60° rotatable horn for conventional PA setups and the VIO X206-100, which features a 100° x 15° waveguide for line-array applications. The removable horn and waveguide allow users to easily adapt the speaker to different environments.
Powered by a 900W RMS Class-D Digipro® G3 amplifier, the VIO X206 delivers an SPL of up to 131 dB while maintaining pristine sound quality. Its advanced DSP processing includes FIR linear phase filters for phase-coherent performance, as well as multiple onboard EQ presets. The speaker is RDNet-enabled, providing real-time remote control and monitoring through Aurora Net software.
Installation options are extensive, with multiple mounting brackets, rigging accessories, and flybars available for wall, pole, truss, or ground-stack configurations. Whether used in live performance settings, corporate AV applications, or fixed installations, the VIO X206 offers a compact yet powerful solution for professional sound reinforcement.
Features:
Ultra-compact, 2-way active loudspeaker with dual 6.5” neodymium LF drivers
Available in two dispersion models: 90° x 60° (rotatable horn) and 100° x 15° (line-array waveguide)
900W RMS Class-D Digipro® G3 amplifier with convection cooling
FIR linear phase filters for high-precision audio reproduction
RDNet-enabled for real-time remote control via Aurora Net
Onboard DSP with multiple EQ and horn selection presets
Rugged wooden cabinet with Polyurea coating for durability
Multiple mounting options, including pole mount, rigging points, and array linking brackets
Specifications:
| Specification | Details |
|---|---|
| Speaker Type | 2-Way Active Loudspeaker |
| Usable Bandwidth (-10 dB) | 66 – 19,500 Hz / 66 – 18,000 Hz (X206-100) |
| Frequency Response (-6 dB) | 70 – 18,000 Hz / 70 – 17,500 Hz (X206-100) |
| Max SPL | 131 dB |
| HF Driver | 1x 1”, 1.75″ voice coil |
| LF Driver | 2x 6.5”, 1.75″ voice coil |
| Directivity (X206) | 60° x 90° (rotatable horn) |
| Directivity (X206-100) | 100° x 15° (H x V) |
| Amplifier Power | 900 W RMS Class-D Digipro® G3 |
| Cooling | Convection |
| Power Supply | Auto-range SMPS |
| DSP Controller | 32-bit |
| AD/DA Converter | 24-bit / 96 kHz |
| Limiter | Peak, RMS, Thermal |
| Processing | FIR Linear Phase Filters |
| Inputs | 1x XLR balanced, 1x RJ45 Link (RDNet), 1x USB (Data Service) |
| Outputs | 1x XLR balanced, 1x RJ45 Link (RDNet) |
| Power Socket | 1x PowerCON TRUE1 In / 1x PowerCON TRUE1 Out |
| Controls | Input Sensitivity Rotary Encoder (10x presets), Horn Model Selection Switch, LED Indicators for On/Status/Signal/Limiter/RDNet |
| Housing | Wooden Cabinet with Polyurea coating |
| Handles | 2 Integrated Handles |
| Rigging Points | 2x M10 Threaded Nuts (top and bottom) |
| Dimensions (W x H x D) | 210 x 650 x 270 mm (8.3 x 25.6 x 10.6 in) |
| Weight | 17.3 kg (38.14 lbs) |
