Description

The Bose L1 PRO16 Portable Line Array is a 1250W powered column PA speaker that’s versatile and simple to use. It functions as a main PA in a wide variety of positions, with a pair able to cover an audience up to 250. The onboard DSP processing, 3-input mixer, and easy-to-use tone presets help working presenters, musicians, instructors, performers, and A/V providers get powerful, clean, and clear sound quickly.

The J-shaped line array provides 180° horizontal and +0/-30 vertical coverage for a wide and even response throughout the room. An array extension raises the height of the mid-high drivers to an appropriate height for ground deployment. The array can be attached without the extension for use on a stage.

The system offers 118 dB of continuous SPL—plenty of volume for small- to mid-sized venues including clubs, houses of worship, conference centers, performance spaces, and meeting rooms. A highly efficient 250W Class-D amplifier powers the sixteen 2″ mid-high drivers, while a 1000W Class-D amplifier powers the 10×18″ racetrack woofer, providing crisp, detailed sound with a wide frequency range from 20 kHz down to 42 Hz.

Features of Bose L1 PRO16

  • All-in-one mixer, PA system, and stage monitoring system
  • Bose line array technology delivers sound evenly across the stage and throughout the audience
  • 16 2-inch neodymium drivers and integrated subwoofer with high-excursion Racetrack driver
  • 2 ToneMatch channels with fixed presets for a vocal microphone and an acoustic guitar
  • Integrated subwoofer with high-excursion neodymium Racetrack driver
  • 2 setup positions: collapsed for smaller spaces or extended for larger ones
  • Ideal for musical performances, mobile DJs, classrooms, business presentations, and other events
  • Use with the free Bose L1 Pro Mix App for wireless control from iOS or Android devices

Specifications of Bose L1 PRO16

Key Specs
Speaker Configuration
16x Full-Range Speaker Column with Subwoofer
Number of Input Channels
3 (2 x Mono, 1 x Stereo)
Amplifier Power Rating
Speakers:
1x 250 W
Subwoofer:
1x 1000
Audio I/O
2x Combo XLR-1/4″ 3-Pin Female Balanced Mic/Line/Hi-Z Input
1x 1/8″ / 3.5 mm TRS Female Unbalanced Line Input
1x 1/4″ TRS Female Unbalanced Line Input
1x XLR 3-Pin Male Balanced Line Outpu
Portable PA System
Speaker Configuration
16x Full-Range Speaker Column with Subwoofer
Number of Input Channels
3 (2 x Mono, 1 x Stereo)
Amplifier Power Rating
Speakers:
1x 250 W
Subwoofer:
1x 1000 W
Amplifier Class
Class-D
Speakers
Full-Range Driver
16x 2″ / 50.8 mm Cone
Subwoofer Driver
1x 18 x 10″ / 457.2 x 254 mm Woofer
Magnet
Neodymium
Signal Processing
Input Pad
No
EQ
HF Shelf
LF Shelf
Semi-Parametric EQ
No
Effects
Reverb
Filters
No
Performance
Frequency Response
42 Hz to 20 kHz
Maximum SPL
112 dB (Continuous)
118 dB (Peak)
Coverage Angle
180° H x 30° V
Protections
No
Connectivity
Audio I/O
2x Combo XLR-1/4″ 3-Pin Female Balanced Mic/Line/Hi-Z Input
1x 1/8″ / 3.5 mm TRS Female Unbalanced Line Input
1x 1/4″ TRS Female Unbalanced Line Input
1x XLR 3-Pin Male Balanced Line Output
Phantom Power
+48 V
Network I/O
No
Wireless Connectivity
Bluetooth
Power
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Physical
Transport Options
1x Handle (Top)
Environmental Resistance
No
Dimensions
79.2 x 18 x 14″ / 201.2 x 45.7 x 35.6 cm
Weight
54.8 lb / 24.9 kg
Packaging Info
Package Weight
62 lb
Box Dimensions (LxWxH)
44 x 25.5 x 17.7″
