Belden 5300FE 2C 18AWG Security & Audio Shielded PVC Cable

Name: Belden 5300FE 2C 18AWG Security &amp; Audio Shielded PVC Cable
SKU: 5300FE
Price: 885.00 AED
Availability: InStock

Brand :

Sku: 5300FE

AED 885.00 Exc VAT

Available in stock

Features

Belden 5300FE 2C 18AWG Security & Audio Shielded PVC Cable. Security & Commercial Audio Cable, Riser-CMR, 2-18 AWG stranded bare copper conductors with polypropylene insulation, Beldfoil® shield and PVC jacket with ripcord

Compare Wishlist

EAN: 610373753115 Category: Speaker Cables

Description
Reviews (0)

Description

Features

Security & Commercial Audio Cable,
Riser-CMR,
2-18 AWG stranded bare copper conductors with polypropylene insulation,
Beldfoil® shield and
PVC jacket with ripcord

Specifications

Element	No. of Elements	Size	Stranding	Material
Conductor(s)	2	18 AWG	7×26	BC – Bare Copper

Element	Material	Nom. Thickness	Nom. Insulation Diameter	Color Code
Conductor(s)	PO – Polyolefin	0.009 in (0.23 mm)	0.062 in (1.6 mm)	Black, Red

Shield Type	Material	Coverage	Drainwire Type
Tape	Bi-Laminate (Alum+Poly)	100%	24 AWG (7×32) TC

Material	Nom. Thickness	Nom. Diameter	Ripcord
PVC – Polyvinyl Chloride	0.017 in (0.43 mm)	0.162 in (4.11 mm)	Yes

Overall Cable Diameter (Nominal)	0.162 in (4.11 mm)

Element	Nom. Conductor DCR	Nom. Capacitance Cond-to-Cond	Nom. Capacitance Cond-to-Other (Conds + Shield)	Max. Current
Conductor(s)	6.5 Ohm/1000ft	53 pF/ft (170 pF/m)	95.5 pF/ft (313 pF/m)	5 Amps per conductor @ 25°C

UL Voltage Rating
300 V (CMR)

UL Temperature	Operating
75°C	-20°C to +75°C

Stationary Min.	Installation Min.
1.6 in (41 mm)	1.6 in (41 mm)

Max. Pull Tension	58 lbs (26 kg)
Bulk Cable Weight	18 lbs/1000ft

Environmental Suitability	Indoor – Riser, Indoor
Flammability / Reaction to Fire	UL 1666 Riser, FT4, IEC 60332-1-2
CPR Compliance	CPR Euroclass: Eca
NEC / UL Compliance	Article 800, CMR
CEC / C(UL) Compliance	CMG
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
UK Regulation Compliance	UKCA Mark
APAC Compliance	China RoHS II (GB/T 26572-2011)
Plenum Number	6300FE

Update and Revision	Revision Number: 0.546 Revision Date: 02-15-2024

Part Numbers

Item #	Color	Putup Type	Length	UPC/EAN
5300FE 0101000	Black	Reel	1,000 ft	612825158981
5300FE 010U1000	Black	UnReel	1,000 ft	612825423362
5300FE 010Z1000	Black	ReelTuff Box	1,000 ft	612825159025
5300FE 0061000	Blue, Light	Reel	1,000 ft	612825350323
