Digital mixing has revolutionized virtually everything in the live-entertainment production workflow. The ultra-affordable S32 digital stage box bridges the gap between the onstage talent, Front of House (FOH) console and the rest of the world with its ultra-fast and rock-solid performance!

Features

• 32 Midas-designed, fully programmable mic preamps for audiophile sound quality
• 16 analog, servo-balanced XLR outputs
• AES50 network ports featuring Klark Teknik?s SuperMAC networking capability for ultra-low jitter and latency
• ULTRANET Connectivity for Behringer’s P16 personal monitoring system for in-ear applications
• Digital audio and control connectivity for Turbosound speaker systems with ULTRANET networking capability
• Automatic AES50 stage-split mode when connected between Behringer X32 Series FOH and monitor consoles
• Dual AES50 ports for cascading additional S16, SD16 or SD8 stageboxes?no merger or router required
• 2 AES-3 ports (AES/EBU), for directly connecting PA system controllers with digital inputs
• Dual ADAT outputs providing 16-channel digital output on two optical TOSLINK* connectors
• Mute All function for quietly patching any inputs on stage
• MIDI In/Out for bi-directional communication between Behringer X32 Series console and on-stage MIDI devices
• Remote operation via shielded CAT5e cable up to 330 ft / 100 m length
• USB connector for system updates via PC
• “Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
• “Built like a tank” yet compact, all-steel 3U rack-mount chassis
• 3-Year Warranty Program*
• Designed and engineered in Germany

Specifications

• Type:Digital Stage Box
• Channels:32
• Inputs – Mic Preamps:32 x XLR
• Phantom Power:Yes
• Outputs – Main:16 x XLR
• Outputs – Digital:2 x Optical Toslink (ADAT), 2 x XLR (AES)
• Data I/O:1 x Ultranet, 2 x AES50
• USB:1 x Type B
• Computer Connectivity:USB
• MIDI I/O:In/Out
• Rackmountable:3U
• Power Source:Standard IEC AC cable
• Height:5.4″
• Depth:9.5″
• Width:19″
• Weight:12.4 lbs.
• Manufacturer Part Number:000-BMC02-00010
