The EVO-X Series strikes the perfect balance between affordability and performance. Positioned in-between the Impact Series and the Delta Series of passive loudspeakers, EVO-X is a new multipurpose lineup of 8 models featuring many useful and practical design elements.
Features
- Dual 18″ passive subwoofer
- MDF construction with tuned front port
- Durable Rhino Rock paint finish
- 2 x 4-way rubberised handles
- Dual speakON compatible and 1/4″ jack inputs
- Continuous 1200w
- Programme 2400w
- Peak 4800w
- 4Ω
- Hi Pass filter output
Specifications
| MODEL NAME | EVO-X218B |
| SYSTEM TYPE | PASSIVE |
| CONFIGURATION | DUAL 18″ SUBWOOFER |
| FREQUENCY RESPONSE (+/-3DB) | 30HZ-250HZ |
| FREQUENCY RANGE (-10DB) | 28HZ-250HZ |
| SENSITIVITY (2.83V/1M) | 107DB |
| SYSTEM RATED IMPEDANCE | 4Ω |
| CALCULATED MAXIMUM SPL @1M | 137DB |
| LOW FREQUENCY TRANSDUCER | |
| SIZE | 470MM / 18″ X 2 |
| VOICE COIL SIZE | 76.2MM / 3″ |
| RATED IMPEDANCE | 8Ω |
| LF POWER (RE:AES-2012) | 2 X 600W |
| POWER | |
| SYSTEM CONTINUOUS POWER | 1200W |
| SYSTEM PROGRAMME POWER | 2400W |
| SYSTEM PEAK POWER | 4800W |
| CROSSOVER FREQUENCY | 150HZ |
| INPUT CONNECTORS | 2 X NL4 (SPEAKON COMPATIBLE) + 2 X 1/4″ JACKS |
| HARDWARE | |
| POLE MOUNT | 2 X 35MM POLE SOCKETS |
| HANDLES | 2 ON SIDES |
| ENCLOSURE | |
| ENCLOSURE MATERIAL | MDF |
| FINISH | RHINO ROCK PAINT |
| GRILLE MATERIAL AND FINISH | 1.2MM STEEL |
| DIMENSIONS – UNPACKED | |
| HEIGHT | 650MM / 25.59″ |
| WIDTH FRONT | 610MM / 24.02″ |
| WIDTH REAR | 610MM / 24.02″ |
| DEPTH | 1020MM / 40.16″ |
| DIMENSIONS – PACKED | |
| HEIGHT | 765MM / 30.12″ |
| WIDTH FRONT | 710MM / 27.95″ |
| WIDTH REAR | 710MM / 27.95″ |
| DEPTH | 1120MM / 44.09″ |
| WEIGHT | |
| NET WEIGHT | 67.3KG / 148.1LBS |
| GROSS WEIGHT | 79.9KG / 175.8LBS |
