Tascam US-4x4HR Desktop 4x4 USB Type-C Audio/MIDI Interface

Tascam US-4x4HR Desktop 4×4 USB Type-C Audio/MIDI Interface

Name: Tascam US-4x4HR Desktop 4x4 USB Type-C Audio/MIDI Interface
SKU: US-4x4HR
Price: 1069.00 AED
Availability: InStock

Brand :

Sku: US-4x4HR

AED 1,122.45 inc VAT

Available in stock

Features

Record or livestream songs, podcasts, and commentary in high resolution to your Mac/Windows computer or iOS mobile device with the Tascam US-4x4HR, a desktop 4x4 USB Type-C audio/MIDI interface designed to deliver comfortable, user-friendly operation, clean audio quality, and simultaneous input of four mics for home recordists and content creators. The inclusion of MIDI ports gives producers an easy way to integrate MIDI gear into their music production setups.

EAN: 043774034680

Compare Wishlist

Category: Audio Video Interfaces Brand: Tascam

Description

Record or livestream songs, podcasts, and commentary in high resolution to your Mac/Windows computer or iOS mobile device with the Tascam US-4x4HR, a desktop 4×4 USB Type-C audio/MIDI interface designed to deliver comfortable, user-friendly operation, clean audio quality, and simultaneous input of four mics for home recordists and content creators. The inclusion of MIDI ports gives producers an easy way to integrate MIDI gear into their music production setups.

Features

Producers, Musicians, and Home Studios
USB Type-C / USB Type-A Connectivity
4 Mic Preamps, 2 Line/Hi-Z In, 2 Line In
2 Headphone Outs, 4 Line Outputs
24-Bit / 192 kHz AD/DA Converters
Bus Power or PSU / Mac, Windows, iOS
Phantom Power, Direct Monitor, MIDI I/O
LED Signal/Peak Indicators
Virtual Loopback for Livestreaming
DAWs, Virtual Instrument, Auto-Tune

Specifications

Form Factor	Tabletop
Display	None
Channels of I/O	Analog: 4 Inputs / 4 Outputs
Maximum Sampling Rate	192 kHz / 24-Bit
Number of Microphone Preamps	4 Preamps
Input Level Adjustment	4 x Knob
Expansion Slots	None

Signal Processing

Pad	None
Gain/Trim Range	Mic/Line/Hi-Z Inputs: 56 dB
High-Pass Filter	None
Solo/Mute	None

Connectivity

Analog Audio I/O	4 x XLR 3-Pin Balanced Mic Input (Front Panel) 2 x 1/4″ TRS Balanced/Unbalanced Line/Hi-Z Input (Front Panel) 2 x 1/4″ TRS Balanced Line Input (Front Panel) 4 x 1/4″ TRS Balanced Line Output 2 x 1/4″ TRS Unbalanced Headphone Output (Front Panel)
Phantom Power	48 V, Selectable On/Off (Applied to All Inputs)
Digital Audio I/O	None
Host Connection / USB	1 x USB Type-C (USB 2.0)
USB (Non-Host)	None
Sync I/O	None
Network I/O	None
MIDI I/O	1 x DIN 5-Pin Input 1 x DIN 5-Pin Output
Wireless Connectivity	None

Performance

Frequency Response	Mic, Line Inputs: 20 Hz to 20 kHz +0/-0.4 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0/-0.4 dB (at 88.2/96 kHz, JEITA) Line Outputs: 20 Hz to 20 kHz +0.2/-0.1 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0.2/-0.4 dB (at 88.2/96 kHz, JEITA)
Maximum Input Level	Mic Inputs: +9 dBu Line Inputs: +20 dBu Hi-Z Inputs: +10 dBV
Maximum Output Level	Line Outputs: +20 dBu
Headphone Output Power	45 mW per Channel into 32 Ohms (0.1% THD)
Impedance	Mic Inputs: 2.2 Kilohms Line Inputs: 10 Kilohms Hi-Z Inputs: ≥ 1 Megohm Line Outputs: 210 Ohms
SNR	Mic Inputs: 110 dB (A-Weighted, Min Gain) Line Inputs: 108 dB (A-Weighted, Min Gain) Line Outputs: 110 dB (A-Weighted, Max Gain)
THD+N	Mic Inputs: 0.0013% (1 kHz, Min Gain) Line Inputs: 0.0011% (1 kHz, Min Gain) Line Outputs: 0.0012% (1 kHz)
Crosstalk	≥ 95 dB (1 kHz)
EIN	-128 dBu

Digital Audio

Sample Rates	44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Sample Rate Conversion	None
Bit Depths	24-Bit
Sync Sources	Internal

Audio Storage & Playback

Memory Card Slot

None

Compatibility

OS Compatibility	macOS 10.13 macOS 11 or Later Windows 7 or Later iPadOS 13 or Later iOS 11 or Later *As of November, 2021: check with manufacturer for the most up-to-date compatibility
Included Software	Cubase LE
Compatible Software (Not Included)	Any Core Audio (Mac) Compliant Software
Included Plug-Ins	Virtual Instruments: SampleTank SE
Supported Drivers/API & Plug-Ins	Core Audio (Mac) ASIO WDM
Processor Requirement	2 GHz or Better
RAM Requirements	2 GB
Mobile Device Compatibility	iPad iPhone
Required Hardware	Available USB 2.0 Port USB Cable (Included)
Internet Connection	Required for Registration, Software/Driver Download

Power

Power Requirements	AC/DC Power Adapter (Not Included) or USB Bus Power
AC/DC Power Adapter	12 VDC, Center-Positive (Included)
Power Consumption	2.25 W

Physical

Operating Temperature	41 to 95°F / 5 to 35°C
Dimensions	11.7 x 6.3 x 2.6″ / 29.6 x 16 x 6.5 cm (Including Controls and Protrusions)
Weight	3.5 lb / 1.6 kg
