The 2-input/2-output Rubix22 USB audio interface from Roland offers a balance of high-fidelity sound, solid build quality, compact size, and powerful features, which give you studio-grade performance just about anywhere you choose to record.
The unit is equipped with two low-noise mic preamps and a Hi-Z jack input for guitars or other high impedance sources. It supports audio resolution up to 24-bit / 192 kHz and features class-compliant Mac and Windows drivers for low latency.
The Rubix22 is well equipped to meet the rigors of the road. Its sturdy and compact metal construction, extensive shielding, and ground lift effectively protect it against radio frequency interference and electrical hums, often found in live venues. It also features big level indicators that clearly show if a channel has incoming signal or if you’re going to overload, critical for working in low-level light environments such as stages.
Connect your Rubix22 to an iPad, and using the software of your choice turn it into a compact system for on-location productions.
Features
- 2 Inputs / 2 Outputs
- 2 Low-Noise Mic Preamps, 48V Phantom
- Hi-Z Input for Guitar
- 24-Bit / 192 kHz Resolution
- Low Latency
- MIDI I/Os
- Extensively Shielded with Ground Lifts
- Powered via USB
- 6-Month Membership to Roland Cloud Pro
- Mac OS, Windows & iPad Compatible
Specifications
| Form Factor | Tabletop |
| Display | None |
| Channels of I/O | 4 Input / 4 Output |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Preamps | 2 Preamps |
| Gain/Trim Range | Line Inputs: -44 to +4 dBu Mic Inputs: -60 to -12 dBu |
| Analog Audio I/O | 1 x Combo XLR-1/4″ TRS Mic/Line/Hi-Z Input 1 x Combo XLR-1/4″ TRS Mic/Line Input 1 x 1/4″ TRS Headphone Output 2 x 1/4″ TRS Balanced Output |
| Digital Audio I/O | None |
| Host Connection / USB | USB Type-B (USB 2.0) |
| MIDI I/O | 1 x DIN 5-Pin Input 1 x DIN 5-Pin Output |
| Wireless Connectivity | None |
| Maximum Input Level | Line Inputs: +18 dBu Mic Inputs: +2 dBu |
| Headphone Output Power | 20 mW per Channel into 47 Ohms |
| Impedance | Headphone Outputs: 47 Ohms Hi-Z Inputs: 500 Kilohms Line Inputs: 15 Kilohms Mic Inputs: > 4 Kilohms (Balanced) Outputs: 2 Kilohms (Unbalanced) |
| Dynamic Range | A/D Converters: 104 dB D/A Converters: 109 dB |
| THD+N | -94 dBu |
| Sample Rates | 44.1 / 48 / 96 / 192 kHz (AD/DA Conversion) |
| Bit Depths | 24-Bit |
| Memory Card Slot | None |
| OS Compatibility | Windows 7 / 8 / 8.1 / 10 macOS 10.10 or Later iOS 9 or Later |
| Power Requirements | USB Bus Power |
| Dimensions | 6.5 x 5.7 x 1.8″ / 165 x 145 x 46 mm |
| Weight | 2.2 lb / 1.0 kg |
| Package Weight | 3.25 lb |
| Box Dimensions (LxWxH) | 10.1 x 8.9 x 3.45″ |
