Description

The VSA 2050 II integrates 20 Class D amplifiers with 3.5″ full range neodymium speakers, delivering a maximum sound pressure level of 96 dB at 30 meters. Its advanced DSP technology allows precise vertical steering and beam control to focus sound where needed, reducing reflections from ceilings and floors. With RDNet compatibility, users can monitor and control the system remotely, adjusting equalization, delay, polarity, and volume. The system includes standard installation accessories and features a robust extruded aluminum cabinet. It supports multiple preset and custom equalizer settings and provides smartphone remote control through the VSA-RC app. Ideal for speech and music applications in reverberant environments, this system ensures clear, focused audio performance.



Features



  • 20 x Class D, 50 W amplifiers

  • 20 x 3.5″ full range neodymium speakers

  • 96 dB Max SPL at 30 meters

  • 48 kHz 32 bit digital signal processing

  • Horizontal dispersion angle of 130°

  • Vertical coverage beam adjustable from 10° to 30°

  • Vertical steering range from 0° to –40°

  • Standard installation accessories included

  • Extruded aluminum body for durability

  • Indicators and controls for EN 60849 monitoring

  • Full RDNet networked control for real-time system monitoring

  • Multiple equalizer presets including speech, music, and custom settings

  • VSA-RC smartphone remote control for beaming, tilt, delay, equalization, polarity, mute, volume, and configuration lock

  • Recessed I/R receiving diode for dedicated remote control without interference

  • Thermal and short circuit protections with soft limiter

  • Convection cooling system

  • CE compliant safety certification



Specifications



Frequency Response100 Hz – 18,000 Hz
Max SPL @ 30m96 dB
Horizontal Coverage130°
Vertical Coverage10° to 30° (adjustable)
Vertical Steering Range0° to –40°
Transducers20 x 3.5″ neodymium full range, 1.0″ voice coil
Input SignalBalanced/unbalanced
Input ConnectorsCeramic screw terminals
Input Sensitivity0 dBu
Processor ProtectionsThermal, short circuit
LimiterSoft limiter
DSP Sampling Rate48 kHz, 32 bit processing
Power Output1300 W Peak, 650 W RMS
CoolingConvection
ComplianceCE certified
Cabinet MaterialExtruded aluminum
Hardware2 x wall mounting flange
ColorsWhite (RAL 9003), Black (RAL 9005), Custom
Dimensions (H x W x D)2070 mm x 125 mm x 97 mm (81.5″ x 4.92″ x 3.82″)
Weight20 kg (44.09 lbs)
Package Dimensions (H x W x D)180 mm x 2264 mm x 200 mm (7.09″ x 89.13″ x 7.87″)
Package Weight31.5 kg (69.45 lbs)
