Description

The NX 945-A W is a professional active speaker that delivers exceptional clarity, extended bass response, and consistent coverage, now available in a clean white finish. Designed for sound providers, DJs, and live performers, it combines a 2100W Class-D amplifier with a 4-inch titanium compression driver and a powerful 15-inch neodymium woofer. The integrated FiRPHASE and Bass Motion Control DSP technologies ensure zero-phase distortion and optimal low-frequency performance. Encased in a robust, tour-ready all-wood enclosure, this versatile speaker is ideal for a variety of applications including flown arrays, FOH setups, stage monitoring, and fixed installations.

Features

  • Up to 135 dB sound pressure level

  • 2100W Class-D bi-amplification

  • Linear frequency response from 45 to 20000 Hz

  • 4″ titanium/neodymium compression driver

  • 15″ neodymium woofer

  • FiRPHASE zero degrees phase technology

  • Bass Motion Control woofer excursion management

  • Six M10 and four Quick Lock rigging points

  • True Outdoor Protection (TOP) PowerCON connectors

  • Rugged all-wood cabinet with white finish

  • Can be used as FOH, monitor, satellite, or flown speaker

Specifications

Frequency Response45 Hz – 20000 Hz
Max SPL @ 1m135 dB
Horizontal Coverage100°
Vertical Coverage70°
Compression Driver1 x 1.4” neo, 4.0” voice coil
Woofer15” neo, 3.5” voice coil
Input SignalBalanced/Unbalanced
Input ConnectorsCombo XLR/Jack
Output ConnectorsXLR
Input Sensitivity-2 dBu / +4 dBu
Crossover Frequency650 Hz
ProtectionsThermal, RMS
LimiterSoft Limiter
ControlsLinear, Boost, Stage, Volume
Total Power2100 W Peak
HF Power700 W Peak
LF Power1400 W Peak
CoolingConvection
Power ConnectionsPowerCON TRUE1 TOP IN/OUT
Safety ComplianceCE compliant
Cabinet MaterialPlywood
Mounting HardwareMultiple M10 and Quick Lock points
Handles1 x Side
Pole Mount35 mm insert
GrilleSteel
ColorWhite
Height705 mm / 27.76 inches
Width420 mm / 16.54 inches
Depth451 mm / 17.76 inches
Weight27.3 kg / 60.19 lbs
Package Height751 mm / 29.57 inches
Package Width506 mm / 19.92 inches
Package Depth474 mm / 18.66 inches
Package Weight31 kg / 68.34 lbs
Part Number (100-120V)13000875
Part Number (220-240V)13000876
EAN (100-120V)8024530021887
EAN (220-240V)8024530022037
