Description

NX 912-A is built to deliver exceptional audio performance with a 1.75″ compression driver, 12″ woofer, and a 2100W bi-amplified Class-D system. Featuring RCF’s proprietary FiRPHASE and Bass Motion Control DSP, this speaker ensures extended bass, phase coherence, and distortion-free sound at up to 130 dB SPL. Its 100° x 60° directivity waveguide and road-ready plywood cabinet make it ideal for FOH setups, stage monitoring, and flown or pole-mounted installations. Engineered for durability and reliability, the NX 912-A is a top choice for touring professionals.



Features



  • Up to 130 dB Sound Pressure Level

  • 2100W Class-D Bi-Amplification

  • 50-20000 Hz linear frequency response

  • 1.75″ Compression Driver

  • 12″ Woofer

  • FiRPHASE zero degrees phase technology

  • Bass Motion Control woofer excursion management

  • Constant directivity waveguide (100° x 60°)

  • Lightweight, rugged all-wood cabinet

  • Flexible mounting options (pole, wall, flown, truss)



Specifications



Frequency Response 50 Hz ÷ 20000 Hz
Max SPL @ 1m 130 dB
Horizontal Coverage 100°
Vertical Coverage 60°
Compression Driver 1 x 1.0″, 1.75″ v.c
Woofer 1 x 12″, 2.5″ v.c
Input Signal Balanced/Unbalanced
Input Connectors XLR, Jack
Output Connectors XLR
Input Sensitivity -2 dBu / +4 dBu
Crossover Frequency 1600 Hz
Protections Thermal, RMS
Limiter Soft Limiter
Controls Linear, Boost, Stage, Volume
Total Power 2100 W Peak
High Frequency Power 700 W Peak
Low Frequency Power 1400 W Peak
Cooling Convection
Power Connections VDE
Cabinet Material Plywood
Hardware Mounting 2 x M10 Top, 1 x M10 each side/bottom/rear
Handles 1 x Side
Pole Mount 35 mm insert
Grille Steel
Color Black
Height 620 mm / 24.41 inches
Width 362 mm / 14.25 inches
Depth 405 mm / 15.94 inches
Weight 20.8 kg / 45.86 lbs
Package Height 666 mm / 26.22 inches
Package Width 461 mm / 18.15 inches
Package Depth 416 mm / 16.38 inches
Package Weight 22.8 kg / 50.27 lbs
