Description

The MR 40T White offers advanced audio performance combined with the versatility of constant voltage operation, making it ideal for commercial and public address systems. Its 70V/100V transformer supports multiple power taps (20 W, 10 W, 5 W, 2.5 W), allowing integration into large distributed speaker networks without complex rewiring. Each speaker features a robust plastic enclosure, a 4″ woofer, and a 1″ dome tweeter with neodymium magnet for clear and balanced audio. With IP 55 protection and a neutral white RAL 9003 color, MR 40T White blends into any environment, indoors or outdoors. Easy to install using the included wall mount bracket, it ensures consistent and high-performance sound delivery in venues like restaurants, retail stores, malls, or theme parks.



Features



  • 40 W (8 ohm) / 20 W – 10 W – 5 W – 2.5 W (70/100V) power handling

  • 108 dB max SPL

  • 70 ÷ 20000 Hz frequency range

  • 110° x 100° coverage angles

  • 1 x 4″ woofer (1″ v.c.)

  • 1 x 1″ dome tweeter (0.8″ v.c.) with neodymium magnet

  • White colour (RAL 9003)

  • IP 55 protection grade

  • Swivel wall mount accessory included

  • 4 pole Euroblock connector

  • Constant voltage transformer with multiple power tap settings

  • Suitable for indoor and outdoor fixed installations



Specifications



Frequency Response 70 Hz ÷ 20000 Hz
Max SPL @ 1m 108 dB
Horizontal Coverage 110°
Vertical Coverage 100°
Directivity Index Q 7
System Sensitivity 86 dB
Nominal Impedance 8 ohm
Power Handling 40 W
Peak Power Handling 160 W PEAK
Protections Bulb lamp
Crossover Frequencies 3000 Hz
Tweeter 1 x 1.0″ dome, 0.8″ v.c., neodymium
Woofer 1 x 4.0″, 1.0″ v.c.
Input Connector Euroblock
Output Connector Euroblock
Constant Voltage Transformer 70/100 V
Power Tap 1 20 W – 500 ohm
Power Tap 2 10 W – 1000 ohm
Power Tap 3 5 W – 2000 ohm
Power Tap 4 2.5 W – 4000 ohm
IP Protection Grade IP 55
Safety Compliance CE compliant
Cabinet Material Plastic
Hardware Wall mount bracket
Grille Aluminium
Color White (RAL 9003)
Height 216 mm / 8.5 inches
Width 154 mm / 6.06 inches
Depth 135 mm / 5.31 inches
Weight 2.3 kg / 5.07 lbs
Package Height 285 mm / 11.22 inches
Package Width 400 mm / 15.75 inches
Package Depth 235 mm / 9.25 inches
Package Weight 5.5 kg / 12.13 lbs
