RCF HL 2260 Horn Loaded Two-Way Array (22.5° x 60°)

The HL 2260 is a professional-grade, horn-loaded, two-way bi-amped array system built for high-output, long-throw, and mid-distance applications. It features two 12″ high-power woofers with 3.5″ voice coils and a titanium dome 4.0″ voice coil compression driver, providing powerful, distortion-free sound with a frequency range of 60 Hz to 20,000 Hz. With a maximum SPL of 141 dB and 1500 W RMS power handling, this compact yet robust system ensures exceptional intelligibility and output for demanding environments. Its 60° x 22.5° constant directivity pattern allows it to be deployed as a point source for mid-range coverage or clustered for focused long-range projection. The enclosure is made from Baltic birch marine plywood with internal metal bracings and finished with a durable polyurea paint. The perforated steel grille includes an open-cell fiber and water-repellent fabric backing, offering IP55-rated protection against the elements. Integrated rigging hardware and Amphenol IP67 connectors make it ready for reliable outdoor and touring use.

Features

• 1500 W RMS system power handling

• 141 dB max SPL

• 60° x 22.5° constant directivity horn-loaded design

• Frequency response: 60 Hz – 20,000 Hz (-10 dB)

• 2 x 12″ woofers with 3.5″ voice coils

• 1 x 4.0″ voice coil titanium compression driver

• Baltic birch marine plywood cabinet with metal internal bracing

• Perforated steel grille with water-repellent fabric backing

• Weather-resistant IP55 rated enclosure

• Amphenol IP67-rated input/output connectors

• Safe and solid side/rear rigging hardware

• CE certified and compatible with top-tier RCF amplifiers
