RCF HDL 28-A 2200 Watts Two Way Line Array Speaker

The RCF HDL 28-A is a versatile and professional active line array speaker designed for use in live sound reinforcement and permanent installations. Equipped with two 8-inch neodymium woofers and a 3-inch titanium diaphragm compression driver, it ensures powerful bass response and crystal-clear high frequencies. Its Class D amplifier delivers up to 2200W of peak power and supports ultra-linear output with minimal distortion. The system includes RDNet network control for comprehensive monitoring, configuration, and tuning of system components. The symmetrical design with coplanar woofers and advanced DSP filtering provides consistent directivity with no roll-off zones. Constructed from a robust composite material with integrated rigging hardware, the HDL 28-A enables fast setup and secure suspension of up to 20 modules. The HDL 36-AS subwoofer can be paired as an ideal suspended low-frequency extension. This system is ideal for concerts, theaters, arenas, and other demanding audio environments.

Features

• 2200W peak two-channel Class D amplifier

• 135 dB SPL maximum sound pressure

• 48 kHz / 32-bit DSP processing

• RDNet network management onboard

• 2 x 8-inch neodymium woofers with 2.5-inch voice coils

• 1.4-inch compression driver with 3.0-inch titanium diaphragm

• Exclusive FiRPHASE filtering technology

• Cutoff frequency at 750 Hz

• Hyper-vented magnetic structures for extended performance

• Integrated rigging system for fast and adjustable array setup

• Optional HDL 36-AS subwoofer for suspended bass reinforcement

• Lightweight composite cabinet with powder-coated grille
