Description

The HD 410T aluminium horn speaker features a robust construction with an aluminium flare and UV-stabilized autoextinguishing ABS rear cover in grey (RAL 7035). It is engineered to deliver high-efficiency sound reproduction with low distortion and exceptional speech intelligibility. The built-in line transformer supports both 70 V and 100 V constant voltage systems, with a rotary dial on the rear for easy power selection across multiple taps. A hi-pass filter protects the driver from damaging low-frequency signals outside its range. Rated IP66, the speaker withstands harsh environmental conditions, operating reliably in temperatures ranging from -25°C to +70°C. Its stainless steel U bracket allows flexible mounting options. The HD 410T is ideal for outdoor public address systems, sports venues, and other applications requiring robust and clear audio performance.



Features



  • Built-in line transformer with multitap power selector on rear cover

  • Hi-pass filter to protect driver from out-of-range low frequencies

  • IP66 weatherproof construction for indoor/outdoor use

  • Aluminium flare with UV-stabilized, autoextinguishing UL-HB ABS rear cover

  • Colour: Grey (RAL 7035)

  • Stainless steel U bracket included for mounting



Specifications



Frequency Response (-10 dB) 180 Hz ÷ 7,000 Hz
Max SPL @ 1 m 130 dB
Coverage Angle 90°
System Sensitivity 112 dB
Power Handling (RMS) 50 W
Peak Power Handling 200 W PEAK
Driver 1 x 2.0″ Compression Driver
Input Connectors Cable
Output Connectors Cable
Constant Voltage Transformer 70/100 V
Power Selection Taps 50 W (200 Ω), 30 W (333 Ω), 25 W (400 Ω), 15 W (667 Ω), 7.5 W (1333 Ω)
IP Protection Grade IP 66
Safety Compliance CE compliant
Cabinet Material Aluminium
Hardware Stainless steel U bracket
Color Grey (RAL 7035)
Depth 393 mm / 15.47 inches
Diameter 430 mm / 16.93 inches
Weight 3.57 kg / 7.87 lbs
Package Height 415 mm / 16.34 inches
Package Width 420 mm / 16.54 inches
Package Depth 430 mm / 16.93 inches
Package Weight 6.06 kg / 13.36 lbs
