Description

The EVOX J8 W by RCF is a compact, high-powered portable PA system in a refined white finish. It integrates a 12” woofer and eight 2” full-range drivers in a vertical array for wide 120° x 30° sound coverage, ideal for audiences both near and far. Powered by a 1400W Class-D amplifier with FiRPHASE DSP processing, the system provides exceptional clarity and punch. Its polypropylene composite cabinet ensures durability while keeping weight to a minimum. With effortless setup, a built-in handle, and compatibility with an optional trolley cover, the EVOX J8 W is the perfect solution for stylish sound reinforcement in mobile or fixed applications.



Features



  • 1400 Watt peak power (700 Watt RMS)

  • Maximum SPL of 128 dB

  • 40 Hz – 20 kHz frequency response

  • 12″ woofer with high-power 2.5″ voice coil

  • 8 x 2″ compact full-range drivers

  • Wide dispersion: 120° horizontal, 30° vertical

  • FiRPHASE DSP for zero-degree phase response

  • High-efficiency Class-D amplifier

  • Durable white PP composite cabinet with steel grille

  • Built-in handle and trolley-compatible cover option

  • Quick setup with pole mounting and SpeakOn connection

  • Ideal for portable and fixed sound applications

  • CE compliant safety design



Specifications



Frequency Response40 Hz – 20000 Hz
Max SPL @ 1m128 dB
Horizontal Coverage120°
Vertical Coverage30°
Full-range Drivers8 x 2.0″, 1.0″ voice coil
Woofer1 x 12″, 2.5″ voice coil
Input SignalBalanced / Unbalanced
Input ConnectorsXLR, Jack
Output ConnectorsXLR
Input Sensitivity2 dBu / +4 dBu
Crossover Frequency220 Hz
ProtectionsThermal, RMS
LimiterSoft Limiter
ControlsVolume, Boost, Mic/Line
Total Power1400 W Peak, 700 W RMS
High Frequency Power400 W Peak, 200 W RMS
Low Frequency Power1000 W Peak, 500 W RMS
CoolingConvection
Power ConnectionVDE
Cabinet MaterialPP Composite
GrilleSteel
Handle1 Top
ColorWhite
Height2285 mm / 89.96 inches
Width400 mm / 15.75 inches
Depth460 mm / 18.11 inches
Weight20.2 kg / 44.53 lbs
Package Height676 mm / 26.61 inches
Package Width451 mm / 17.76 inches
Package Depth581 mm / 22.87 inches
Package Weight29.9 kg / 65.92 lbs
Safety CertificationCE compliant
