The EVOX J8 W by RCF is a compact, high-powered portable PA system in a refined white finish. It integrates a 12” woofer and eight 2” full-range drivers in a vertical array for wide 120° x 30° sound coverage, ideal for audiences both near and far. Powered by a 1400W Class-D amplifier with FiRPHASE DSP processing, the system provides exceptional clarity and punch. Its polypropylene composite cabinet ensures durability while keeping weight to a minimum. With effortless setup, a built-in handle, and compatibility with an optional trolley cover, the EVOX J8 W is the perfect solution for stylish sound reinforcement in mobile or fixed applications.
Features
1400 Watt peak power (700 Watt RMS)
Maximum SPL of 128 dB
40 Hz – 20 kHz frequency response
12″ woofer with high-power 2.5″ voice coil
8 x 2″ compact full-range drivers
Wide dispersion: 120° horizontal, 30° vertical
FiRPHASE DSP for zero-degree phase response
High-efficiency Class-D amplifier
Durable white PP composite cabinet with steel grille
Built-in handle and trolley-compatible cover option
Quick setup with pole mounting and SpeakOn connection
Ideal for portable and fixed sound applications
CE compliant safety design
Specifications
| Frequency Response | 40 Hz – 20000 Hz |
| Max SPL @ 1m | 128 dB |
| Horizontal Coverage | 120° |
| Vertical Coverage | 30° |
| Full-range Drivers | 8 x 2.0″, 1.0″ voice coil |
| Woofer | 1 x 12″, 2.5″ voice coil |
| Input Signal | Balanced / Unbalanced |
| Input Connectors | XLR, Jack |
| Output Connectors | XLR |
| Input Sensitivity | –2 dBu / +4 dBu |
| Crossover Frequency | 220 Hz |
| Protections | Thermal, RMS |
| Limiter | Soft Limiter |
| Controls | Volume, Boost, Mic/Line |
| Total Power | 1400 W Peak, 700 W RMS |
| High Frequency Power | 400 W Peak, 200 W RMS |
| Low Frequency Power | 1000 W Peak, 500 W RMS |
| Cooling | Convection |
| Power Connection | VDE |
| Cabinet Material | PP Composite |
| Grille | Steel |
| Handle | 1 Top |
| Color | White |
| Height | 2285 mm / 89.96 inches |
| Width | 400 mm / 15.75 inches |
| Depth | 460 mm / 18.11 inches |
| Weight | 20.2 kg / 44.53 lbs |
| Package Height | 676 mm / 26.61 inches |
| Package Width | 451 mm / 17.76 inches |
| Package Depth | 581 mm / 22.87 inches |
| Package Weight | 29.9 kg / 65.92 lbs |
| Safety Certification | CE compliant |
