Description

The COMPACT C 32 is a multipurpose two-way point source speaker engineered for premium performance in near and mid-distance applications. Its internal components include a 12″ high-power neodymium woofer and a 3.0″ voice coil neodymium compression driver. Together, they deliver clear, distortion-free sound with a wide 100° x 50° constant directivity waveguide, which is rotatable for flexible deployment.

Built with high-quality birch plywood and coated with rugged polyurea, the cabinet combines robust construction and sleek aesthetics. Installation is easy thanks to the multiple rigging points located on the top, bottom, rear, and sides, with optional mounting accessories available. The system is compatible with RCF’s high-powered XPS Series amplifiers and meets EN 54-24:2008 certification standards, making it suitable for both entertainment and voice alarm applications.

Features



  • 600 W power handling (RMS)

  • 137 dB maximum SPL

  • 54 ÷ 20000 Hz frequency response

  • 100° x 50° rotatable constant directivity waveguide

  • 1 x 12″ high-power neodymium woofer

  • 1 x 3.0″ v.c. neodymium compression driver

  • High-quality birch plywood cabinet with polyurea coating

  • Steel front grille with protective cloth

  • Multiple rigging points for flexible mounting

  • SPEAKON input/output connectors

  • EN 54-24:2008 certified

Specifications



Frequency Response (-10 dB)54 Hz – 20000 Hz
Max SPL @ 1 m137 dB
Horizontal Coverage Angle100°
Vertical Coverage Angle50°
Directivity Index (Q)10
System Sensitivity97 dB
Nominal Impedance8 ohm
Power Handling600 W RMS / 2400 W Peak
Crossover Frequency1100 Hz
ProtectionsDynamic Active Mosfet
Recommended AmplifiersXPS 16K, QPS 10K, IPS Series, DMA 504
Compression Driver1 x 1.4″ neo, 3.0″ v.c
Woofer1 x 12″ neo, 3.5″ v.c
Input/Output ConnectorsSpeakon (in/out)
IP Protection GradeIP 21C
Safety CertificationsCE, EN 54-24:2008
Cabinet MaterialBirch plywood with polyurea coating
GrilleSteel with protective cloth
Mounting Hardware4 x M8, 14 x M10 points
ColorBlack (RAL 9005)
Dimensions (H x W x D)620 x 361.8 x 404 mm
Weight23.5 kg
Shipping Dimensions (H x W x D)665 x 442 x 400 mm
Shipping Weight25.5 kg
