Description

The ART 710-A MK5 stands out with its precision-built 1.75″ compression driver for superior vocal clarity and a 10″ woofer that delivers deep, linear bass response. Engineered for power and reliability, it boasts a 1400W Class-D amplifier managed by advanced DSP processing. This includes dynamic crossover, phase correction, equalization, and protection features. The speaker incorporates RCF’s FiRPHASE technology for phase-coherent sound and the XBOOST enhancer for added bass depth. Built with a rugged polypropylene composite cabinet and top-tier transducers, it’s a perfect stage companion for professionals demanding quality, clarity, and punch in compact form.



Features



  • 129 dB Max SPL

  • 1400 W 2-way peak power

  • 90° x 70° wide dispersion constant directivity horn

  • 1.75″ high-definition compression driver

  • 10″ high-performance woofer

  • Innovative DSP processing with speaker protection

  • FiRPHASE technology for phase alignment

  • XBOOST Low Frequencies Enhancer

  • Polypropylene composite cabinet with pole mount and M10 rigging points

  • Ergonomic design with top handle for easy transport



Specifications



Frequency Response 50 Hz ÷ 20000 Hz
Max SPL @ 1m 129 dB
Horizontal Coverage 90°
Vertical Coverage 70°
Compression Driver 1 x 1.0”, 1.75” v.c
Woofer 1 x 10”, 2.5” v.c
Input Signal Balanced / Unbalanced
Input Connectors XLR, Jack
Output Connectors XLR
Input Sensitivity -2 dBu / +4 dBu
Mic Input Sensitivity -32 dBu
Crossover Frequency 1600 Hz
Protections Thermal, RMS
Limiter Soft Limiter
Controls Volume, Boost, MIC/Line
Total Power 1400 W Peak
High Frequencies Power 400 W Peak
Low Frequencies Power 1000 W Peak
Cooling Convection
Power Connections VDE
Cabinet Material PP Composite
Hardware 2 x M10
Handles 1 on top
Pole Mount 35 mm insert
Grille Steel
Color Black
Height 548 mm / 21.57 inches
Width 340 mm / 13.39 inches
Depth 305 mm / 12.01 inches
Weight 14.2 kg / 31.31 lbs
Package Height 585 mm / 23.03 inches
Package Width 425 mm / 16.73 inches
Package Depth 405 mm / 15.94 inches
Package Weight 16.8 kg / 37.04 lbs
Safety Compliance CE compliant
