RCF 8000 Series UP 8501 Power Amplifier (1 x 500 W)

The UP 8501 is a 500 W power amplifier engineered with RCF’s advanced digital amplification and power supply technology. Operating in Class D, it ensures high efficiency while delivering pro-audio grade performance. It supports both AC and 48 V DC power supplies, ensuring operational continuity even during mains failure—ideal for voice alarm systems. This amplifier features two inputs per channel, integrated priority circuitry for emergency message delivery, and front-panel status LEDs for power and fault monitoring. Unlike traditional models, the UP 8501 does not use output line transformers, contributing to its compact 1U rack-mount design and lightweight build. Certified to EN 54-16 for use in voice evacuation systems, the UP 8501 is the perfect match for the DXT 7000 series, delivering safety, clarity, and reliability in critical environments.

Features

• 500 W power amplifier with Class D digital technology

• Dual power supply: 220–240/115 V AC and 48 V DC backup

• 2 inputs per channel with priority circuit

• High-efficiency performance with pro-audio quality

• Status LEDs on front panel for monitoring

• No output line transformers for compact and lightweight design

• EN 54-16 certified for voice alarm systems (with DXT 7000)

• Forced-air cooling and full protection circuitry

• 1U rack-mountable metal chassis

Specifications
