Power your next event with the JBL IRX ONE, an all-in-one column PA speaker that features a 3-channel mixer and Bluetooth 5.0 audio steaming, all packed into an easy-to-use system that can be carried with one hand. The IRX ONE is inspired by the large-scale concert line array with incredible directivity control that results in a custom-tuned, C-shaped array. The integrated 1300W amplifier powers the six 2″ high-frequency drivers and the 8″ woofer, which combine for a frequency response of 40 Hz to 18 kHz.
The rear panel provides two combo XLR-1/4″ inputs with +48V phantom power that can handle condenser microphones. A 1/4″ Hi-Z input supports instruments, such as guitar and bass, while the 1/4″ output sends the mix to another IRX ONE for stereo operation. Other notable features include dbx automatic feedback suppression (AFS), 5 EQ presets, Soundcraft audio ducking, and Bluetooth 5.0 audio streaming ensure a professional experience from start to finish.
FEATURES
- 1300W of Power
- 118 dB Maximum SPL
- 8″ Low-Frequency Woofer
- 6 x 2″ High-Frequency Drivers
- 3-Channel Mixer with Bluetooth Audio
- Two Combo XLR-1/4″ Mic/Line Inputs
- 1/4″ Hi-Z Input + 1/4″ Output + BT SBC
- 2-Band EQ, Feedback Suppression, +48V
- Includes System Presets
SPECIFICATIONS
Key Specs
| Speaker Configuration | 1x 2-Way Speaker Column with Subwoofer |
| Number of Input Channels | 3 (3 x Mono) |
| Amplifier Power Rating | 1x 1300 W Peak |
| HF Driver | 6x 2″ / 5.1 cm Tweeter |
| Audio I/O | 2x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Mic/Line Input
1x 1/4″ TRS Female Balanced/Unbalanced Line/Inst Input
1x 1/4″ TRS Female Balanced Line/Mix Output |
Portable PA System
| Speaker Configuration | 1x 2-Way Speaker Column with Subwoofer |
| Number of Input Channels | 3 (3 x Mono) |
| Amplifier Power Rating | 1x 1300 W Peak |
| Amplifier Class | Class-D |
Speakers
| Enclosure Type | Bass-Reflex |
| HF Driver | 6x 2″ / 5.1 cm Tweeter |
| Subwoofer Driver | 1x 8″ / 20.3 cm |
| Subwoofer Voice Coil | 1.5″ / 38.4 mm |
| Magnet | Subwoofer:
Ferrite
HF Driver:
Neodymium |
Signal Processing
| Crossover | 260 Hz |
| EQ | 1x HF Shelf
1x LF Shelf |
| Semi-Parametric EQ | No |
| Effects | Yes |
| Dynamic Processing | Limiter |
Performance
| Frequency Response | 50 Hz to 18 kHz -3 dB |
| Frequency Range | 40 Hz to 20 kHz -10 dB |
| Maximum SPL | 118 dB |
| Coverage Angle | 160° H x 80° V |
| I/O Impedance | Mic Input:
4.4 Kilohms (Balanced/Unbalanced)
1/4″ Hi-Z Input:
1 Megohms (Balanced) |
Connectivity
| Audio I/O | 2x Combo XLR-1/4″ 3-Pin Female Balanced/Unbalanced Mic/Line Input
1x 1/4″ TRS Female Balanced/Unbalanced Line/Inst Input
1x 1/4″ TRS Female Balanced Line/Mix Output |
| Phantom Power | +48 V |
| Mobile App Compatible | No |
| Network I/O | No |
| Wireless Connectivity | Bluetooth |
Power
| AC Input Power | 100 to 120 VAC, 60 Hz |
| AC Power I/O | 1x IEC Input |
Physical
| Transport Options | Subwoofer:
1x Handle (Top) |
| Construction Material | Perforated Metal Grille, Polypropylene |
| Dimensions | 23.5 x 15.7 x 10.5″ / 597 x 400 x 267 mm |
| Weight | 34.2 lb / 15.5 kg |
Packaging Info
| Package Weight | 41.5 lb |
| Box Dimensions (LxWxH) | 29 x 20.5 x 16″ |
