Ecler WPNET4KV Wall-Mounted AV Control Panel for EclerNet Systems

WPNET4KV is an EclerNet compatible wall panel, featuring an LCD screen, a digital rotary encoder and 4 direct selection keys. Its end-user control features are volume control, source and preset selection functions. Equipped with Ethernet interface and compatible with PoE (Power over Ethernet) or local power supply.

FEATURES

• Single European electrical box format, compatible with flush and surface installation (surface box supplied as standard)
• Compatible with circular base installation box, with diameter ≥ 60 mm, from products with serial number equal to or greater than those specified in the previous chapter
• Power over Ethernet (PoE) or optional external power supply, WP24-PSU model
• Ethernet communication interface, RJ45 connector
• 128×128 pixels LCD display
• Digital rotary control (encoder) + 4 programmable keys
• MIMO4040DN matrix remote control functions: audio source selection, preset selection, volume / MUTE adjustment, equalization settings, etc. (depending on models, refer to this manual and the EclerNet Manager application manual)

APPLICATIONS

Retail   Education   Corporate   Sports & Wellness   Hospitality

SPECIFICATIONS

• Display: 128×128 pixel LCD
• Controls: Digital rotary encoder and 4 programmable selection keys
• Communication Interface: Ethernet (RJ45 connector)
• Power Supply:
  • Power over Ethernet (PoE) compliant (IEEE 802.3af, Class 0)
  • Optional external power supply: 12–24VDC (WP24-PSU model)
• Power Consumption:
  • From PoE: 35mA / 1.6W
  • From external power supply: 1.5W
• Dimensions: 86mm (W) x 86mm (H) x 30mm (D)
• Weight: 120g
• Mounting: Single European electrical box format; compatible with flush and surface installations (surface box supplied as standard)
• Compatibility: EclerNet devices, including MIMO4040DN matrix
• Firmware: Upgradeable via EclerNet Manager application
