eCOMPACT4BT is a desktop and 19″ rackmount 4-channel mixer with Bluetooth® for professional installation. Simple to operate, suitable for both experienced and novice users. Features 4 microphone inputs, 6 stereo line inputs, USB charging port, Bluetooth® wireless connection and a mini-jack input for external devices. All microphone inputs have a switchable high-pass filter. 3-band tone control and ALT Send (sub-mix channel) on all channels.
FEATURES
- 4-channel analogue mixer, one channel with adjustable Talkover
- 19″ rack installation or desktop
- 4 microphone inputs, one with combo connector (front panel)
- 48 V phantom power for microphone inputs (rear panel selector)
- 6 RCA stereo line inputs, and one stereo mini-jack line input on front panel
- Class 1 Bluetooth® wireless connection (up to 25 m range under ideal conditions)
- Source selector on each channel
- Selectable high-pass filter for MIC inputs (fc = 100 Hz)
- 3-band tone control (treble, midrange and bass)
- Input signal presence and overload indicators
- 45 mm faders
- ALT OUT send per channel. Sub-mix available
- USB port for charging mobile devices
- Balanced main output (MAIN OUT), XLR connector
- Stereo/mono switch for main output
- Signal indicators (LED) with measured output signal selector (MAIN OUT or ALT OUT)
- Unbalanced alternative or sub-mix output (ALT OUT), RCA connector
- Sub-bass or auxiliary output (SUB OUT), XLR connector. Mono sum of the main output signal
- Low-pass filter available on SUB OUT (fc = 150 Hz)
- Front panel headphone output, mini-jack
- 3URMKIT included (rack-mount accessory)
- Universal external power supply with interchangeable connectors (American, European, British and Chinese).
APPLICATIONS
Education Leisure Sports & Wellness
SPECIFICATIONS
ANALOGUE AUDIO INPUT PORTS
Number of input ports
- 4 channels:
- 4 MIC ports
- 6 ST LINE ports
Connection type
- LINE: RCA
- 1 COMBO MIC (Front panel)
Input sensitivity
- LINE, LINE A, LINE B: 0dBV
- MICRO (BAL): -35dBV
- AUX INPUT IN1: -10dBV
- BT INPUT: -10dBVFS
Input impedance
- LINE, LINE A, LINE B: 50k?
- MICRO (BAL): <1k?
- AUX INPUT IN1: 316?
CMRR
- BAL INPUTS >75dB @ 1kHz
Phantom voltage
- +48VDC, externally selectable
ANALOGUE AUDIO OUTPUT PORTS
Number of output ports
- 3: MAIN OUT, SUB OUT, ALT OUT
Connection type
- Main: XLR
- Sub: XLR
- Alt: RCA
Max output level
- TBC
Output impedance
- TBC
ANALOGUE MONITOR PORTS
Headphones
- ST, mini-jack (200mW)
Channels
- TBC
DEVICE CONTROL
Tone Control
- 3-way tone control
Tone Frequency Cut
- BASS 100Hz, ± 15dB
- MID 2kHz, ± 15dB
- TREBLE 10kHz, ± 15dB
Talkover
- Yes
Control Buttons
- Input selection, ALT OUT send, PAIR, HPF switches, talkover, main out ST/MONO, POWER ON switch, LPF switch, PHANTOM
Status Indicators
- SP, CLIP, main OUT – ALT OUT vumeter, POWER LED, PHANTOM LED, talkover
ELECTRICAL
Power supply
- External power supply
AC mains requirement
- 100-240 VAC + External PSU 17.5VDC
AC mains connector
- DC power supply connector
Power consumption
- 15 W
PHYSICAL
Operating temperature
- Min: -10°C ; 14°F
- Max: 40°C ; 104°F
Operating humidity
- <85% HR
Storage temperature
- Min: -10°C ; 14°F
- Max: 40°C ; 104°F
Storage humidity
- <90% HR
Installation options
- Desktop, 19″ rack format (3RU)
Optional accessories
- Rack-mount accessory (3URMKIT)
Dimensions
- 440 x 132 x 125 mm / 17.32 x 5.2 x 4.92 in. (WxHxD)
Weight
- 3.0 kg / 6.61 lb
Shipping dimensions
- TBC
Shipping weight
- TBC
SIGNAL
- THD + Noise
- LINE: <0,03%
- MICRO: <0,06%
- AUX: <0,03%
- BT INPUT: <0,05%
