Ecler ARQISSB6TiBK 2×6.5-Inch 120W RMS Subwoofer Passive Wooden Speaker for Commercial Sound Systems

The Ecler ARQISSB6Ti is a wooden wall-mount subwoofer reinforcement cabinet with a slim and compact format, stylish aesthetics, excellent sound quality and long-term reliability, featuring a 6.5″ driver and a passive 6.5″ radiator. 120 WRMS power @ 8 ? and integrated 70/100V line transformer with 60 and 120W taps. Internal LPF with OFF, 120HZ and 150 HZ cut-off frequency selections. Installation U-bracket included. Available in white and black finish. ARQISi SERIES has been specifically designed to fulfil permanent installation requirements where a perfect balance between sound performance and architectural/interior’s design matching is a must.

FEATURES

• 6,5″ subwoofer + 6,5″ passive radiator
• Ready for 70/100V installations: power selector 60/120W & 8 ?
• Euroblock connector and spring-loaded input terminals
• LPF cut-off frequency selection: OFF/ 120Hz / 150Hz
• U Wall-mount hardware included
• Available in black (RAL 9005) and white (RAL9003) colour
• EASE files available

APPLICATIONS

Retail   Education   Corporate   Leisure   Sports & Wellness   Hospitality

SPECIFICATIONS

System Specifications

• Type: Passive 1-way subwoofer
• Frequency Response: 50 Hz – 1.5 kHz
• Power Handling:
  • RMS: 120W
  • Peak: 480W
• Sensitivity: 86 dB (1W/1m)
• Maximum SPL:
  • Continuous: 107 dB
  • Peak: 113 dB
• Nominal Impedance: 8Ω
• Recommended Amplifier Power: 250W RMS
• Low-Pass Filter (LPF): Selectable OFF / 120Hz / 150Hz
• High-Pass Protection Filter: Recommended at 55 Hz with a minimum 12 dB/octave slope

Driver Configuration

• Drivers: 2 × 6.5″ subwoofers
• Radiator: 1 × 6.5″ passive radiator
• Ways: 1-way subwoofer

Connectivity & Controls

• Input Connectors: Euroblock connector and spring-loaded input terminals
• Power Selector: 60W / 120W / 8Ω
• Low-Pass Filter Selector: OFF / 120Hz / 150Hz

Physical & Environmental

• Enclosure Material: MDF (Medium Density Fiberboard)
• Grille Material: Steel
• Grille Fixing System: Screw fixation
• Flying Points: 2 × M8
• Mounting Options: Surface, wall, desktop
• Environmental Rating: IP31
• Operating Temperature: -10°C to 40°C
• Operating Humidity: <85% RH
• Storage Temperature: -10°C to 40°C
• Storage Humidity: <90% RH
• Included Accessories: U-bracket, 5mm Allen key, 6mm Allen key
• Finish Colors: Black (RAL9005) or White (RAL9003)

Dimensions & Weight

• Dimensions (WxHxD): 390 × 250 × 130 mm
• Weight: 8.2 kg
• Shipping Dimensions (WxHxD): 535 × 535 × 470 mm
• Shipping Weight: 10.2 kg
