The VIO X15 is the largest model in dBTechnologies’ VIO X series, designed for professional audio applications requiring high output and superior sound clarity. Featuring a 15” neodymium LF driver and a 1.4” HF driver, the VIO X15 provides a precise 60° x 40° dispersion via its rotatable horn, ensuring optimal coverage for different setups. It excels as a standalone PA system, stage monitor, or a component in larger VIO systems when paired with VIO S118 and VIO 118R subwoofers.
Powered by a 900W RMS Class-D Digipro® G3 amplifier, the VIO X15 achieves an impressive SPL of 133.5 dB while maintaining audio fidelity. Advanced DSP processing with FIR linear phase filters ensures outstanding intelligibility and uniform sound distribution across the listening area. Onboard presets allow users to adjust high-pass filters and EQ settings for various applications, including Wedge and Full-range modes.
Seamlessly integrating with RDNet, the VIO X15 enables real-time remote monitoring and control via Aurora Net software. Its durable wooden cabinet, finished with Polyurea coating, offers multiple mounting options, including a 36mm pole mount, rigging points for flying, and a 50° wedge angle for stage monitoring.
Features:
-
2-way active loudspeaker with a 15” neodymium LF driver
-
900W RMS Class-D Digipro® G3 amplifier for high SPL output
-
FIR linear phase filters for superior audio clarity
-
RDNet-enabled for real-time remote monitoring and control
-
Rotatable 60° x 40° horn for flexible dispersion
-
Preset EQ modes for Wedge, Full-range, and High-Pass filtering
-
Rugged wooden enclosure with Polyurea coating for durability
-
Multiple mounting options, including pole mount, rigging points, and wedge configuration
Specifications:
Specification | Details |
---|---|
Speaker Type | 2-Way Active Loudspeaker |
Frequency Response (-10 dB) | 55 – 22,000 Hz |
Frequency Response (-6 dB) | 72 – 21,000 Hz |
Max SPL | 133.5 dB |
HF Driver | 1x 1.4”, 2.5″ Neodymium |
LF Driver | 1x 15”, 3″ Neodymium |
Directivity | 60° x 40° |
Horn | Rotatable Horn |
Amplifier Power | 900 W RMS Class-D Digipro® G3 |
Cooling | Convection |
Power Supply | Auto-range SMPS |
DSP Controller | 28/56-bit |
AD/DA Converter | 24-bit / 48 kHz |
Limiter | Peak, RMS, Thermal |
Processing | FIR Linear Phase Filters |
Inputs | 1x XLR balanced, 1x RJ45 Link (RDNet) |
Outputs | 1x XLR balanced, 1x RJ45 Link (RDNet) |
Power Socket | 1x PowerCON TRUE1 In / 1x PowerCON TRUE1 Out |
Controls | Rotary Encoder (8x EQ, HPF presets), Mic/Line switch, Input sensitivity knob |
Special Features | Opto-isolated floating preamp |
Housing | Wooden Cabinet with Polyurea coating |
Handles | 1x (Top), 2x (Side) |
Wedge Angle | 50° Monitor Use |
Rigging Points | 12x M10 Thread + 4x Fast Lock Pins |
Pole Mount | Ø36 mm |
Dimensions (W x H x D) | 400 x 750 x 475 mm (15.74 x 29.52 x 18.7 in) |
Weight | 25.4 kg (55.99 lbs) |
