The 46-120T from Cloud USA is a four-zone integrated mixer and amplifier well suited for supermarkets, retail stores, restaurants, bars, and other retail or industrial applications. The unit provides with individual source selection and volume control of up to six audio sources and two microphone inputs across four zones. Each zone provides 120W (4 Ohm) output or 120W (70/100V) output with the internal transformer modules pre-installed.
Each zone offers music level and source selection knobs, as well as level knobs for the two microphone inputs. Additionally, there are LF and HF controls for each zone, allowing for a customized sound for each zone. There are several options for remote source selection, volume control, and paging systems making the system a feature-packed single-box solution. The 46-120T ships with a power cord, a set of mating connectors for all real panel multi-pin screw-terminals, a set of four plastic feet, and a front panel security cover with mounting hardware.
Features
- Eight input (6 line + 2 mic) mixer amplifier for four zones
- Provides versatile music, paging and announcement facilities in each zone
- Front panel user controls for music source, music level and level of each microphone, for each zone
- Six (unbalanced) stereo line inputs with individual gain trim controls
- Selectable LINE 6 priority in Zone 1, with choice of release times
- Two balanced mic inputs; 15 V phantom power selectable on either or both
- MIC 1 input can be configured as telephone system interface
- Contact closure access port for paging zone selection – most OEM paging systems supported
- Selectable VOX-triggered mic-over-music priority
- Sensitivity and HF/LF EQ adjustment for mic inputs (rear panel)
- Front panel preset controls for HF/LF EQ for each zone output
- 4 x 120 W power output (4 ohms)
- Includes CXL-46T 70/100V transformers factory-installed in all channels
- Dynamic clip limiting in power amplifier stage
- Zones 1 & 2 auxiliary line level outputs (pre-power amplifier), for connection of additional external amplifiers
- Transformer-isolated auxiliary output with independent mic and music level control – for use with telephone MOH systems
- Aux output source selection (internal jumper) – fixed source or mix of Mic 1 and Zone 1 music source
- Zone 1 Facility Port (RJ45) for connection of optional LM-2 Series mic/line remote input/control modules via screened Cat 5
- Selectable 65 Hz high-pass filter per-output (for use with 70/100 V-line systems)
- Music Mute control input (N/O or N/C) for interface to emergency system
- Compatible with standard Cloud remote control plates: RL Series (music level) and RSL Series (music level and source selection), per-zone
- Optional CDI-46 digital interface card with Cloud Digital Paging System port for direct interface to PM Series paging microphones, RS-232 serial port and RJ45 Ethernet port
- Optional EQ cards available to suit various popular installation loudspeakers may be fitted in any or all outputs
- Energy-saving auto power-down function, Ethernet-controllable (when CDI-46 is fitted)
- Remote standby mode control by contact closure
- Variable–speed fan cooling
- 2U 19” rack-mounting unit
Specifications
| Number of Channels | |
| Amplifier Power Rating | |
| Load Impedance / Voltage | |
| Rackmount Size |
| Form Factor/Type | |
| Number of Channels | |
| Number of Zones | |
| Amplifier Power Rating | |
| Load Impedance / Voltage |
| Protections | |
| Frequency Response | |
| Input Sensitivity | |
| I/O Impedance | |
| Input Gain/Trim Range | |
| Headroom | |
| Noise | |
| EIN | |
| THD+N | |
| Distortion | |
| CMRR |
| EQ |
| AC Input Power | |
| Power Consumption |
| Rackmount Size | |
| Cooling | |
| Dimensions | |
| Weight |
