With coaxial two-way drivers, the 125-watt DesignMax DM6C loudspeaker offers rich lows and clear, intelligible highs – along with premium aesthetics that complement any commercial sound installation. The DM6C features a 6.5-inch woofer and a 1.25-inch coaxial tweeter mounted within the Dispersion Alignment system, delivering a frequency range of 59 Hz – 20 kHz. The in-ceiling DM6C is installed easily via QuickHold mounting arms.
Features
Combine DesignMax models to complete any design, big or small
12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options
Deliver rich lows and clear, intelligible highs with coaxial two-way drivers
no DSP or EQ required. For even better sound, use select Bose DSPs and amplifiers to enable Bose loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level
Ensure a consistent listening experience
Throughout the room with the Dispersion Alignment system, which matches the acoustic pattern of the woofer to the pattern of the tweeter
Blend with any room design with elegant form factors
Minimum-bezel grilles available in black or white, and removable logos
Reduce installation time
with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage
Install easily with industry-standard accessories
All models include Euroblock connectors; in-ceiling models include plenum-rated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier
Specifications
Frequency Response (+/-3 dB)
70 – 20,000 Hz
Nominal coverage (H x V)
120° conical
Power Handling, peak
500 W
Maximum SPL @ 1m
109 dB
Frequency Range (-10 dB)
59 – 20,000 Hz
Power Handling, long-term continuous
125 W
Sensitivity (SPL/1W @ 1 m)
88 dB
Nominal Impedance
8 Ω (transformer bypass)
