Description

Audio engineers and rental houses looking for a portable, versatile, and simple-to-use PA will be impressed with the 15″ Alto Professional TX315, a 700W powered PA speaker that functions as a main PA in a wide variety of positions and with a pair, can cover an audience up to 250. The simple interface helps working presenters, musicians, instructors, performers, and A/V providers get powerful, clean, and clear sound easily.

The speaker provides 90×60° coverage and 119 dB of peak SPL, plenty of volume for smaller venues including houses of worship, conference centers, performance spaces, and meeting rooms. The highly efficient 700W Class-D amplifier powers the 1″ titanium compression driver and 15″ woofer, providing crisp, detailed sound with a wide frequency range from 20 kHz down to 65 Hz. The rear panel features a single combo XLR-1/4″ mic/line input and an XLR link output to connect additional speakers. Controls for volume and contour allow you to dial in your best sound, while the ground-lift switch removes any ground loop hum for clean, clear audio. The trapezoidal shaped enclosure includes a 1.4″ pole cup, allowing you to use the speaker upright for mains or on its side for wedge monitoring positioning.



FEATURES

  • For Mains or Monitor Wedge
  • For Small Spaces / Up to 250 People
  • Clean, Clear, Loud & Portable, 31.4 lb
  • 90×60° Coverage, 65 Hz to 20 kHz
  • Combo XLR-1/4″ Input + XLR Link Output
  • Integrated Handles for Easy Transport
  • Precision High-Frequency Horn
  • Full-Sized Steel Grille
  • 1.4″ Pole Cup



SPECIFICATIONS

Key Specs
Configuration
Active 2-Way
Enclosure Type
Bass-Reflex Loudspeaker/Floor Monitor
Total Power Capacity
700 W
HF Driver
1 x 1″ / 25.4 mm Titanium Compression Driver
MF Driver
No
LF Driver
1x 15″ / 38.1 cm Woofer
Wireless Connectivity
No
Color
Black



Enclosure Type
Bass-Reflex Loudspeaker/Floor Monitor
Total Power Capacity
700 W
Amplifier Power Rating
350 W RMS
700 W Peak
Amplifier Class
Class-D



Drivers
HF Driver
1 x 1″ / 25.4 mm Titanium Compression Driver
MF Driver
No
LF Driver
1x 15″ / 38.1 cm Woofer
LF Voice Coil
2″ / 50.8 mm



Performance
Frequency Response
65 Hz to 20 kHz -3 dB
Maximum SPL
119 dB (Peak)
Coverage Angle
90° H x 60° V
Protections
Crossover Overload, Output Limiter



Connectivity
Audio I/O
1x Combo XLR-1/4″ TRS Female Balanced/Unbalanced Mic/Line Input
1x XLR 3-Pin Male Link Output
Network I/O
No
USB I/O
No
Wireless Connectivity
No
Mobile App Compatible
No



Signal Processing
Crossover
2.2 kHz
EQ
Contour
Parametric EQ
No
Semi-Parametric EQ
No
Filters
No
Alignment Delay
No
Phase Adjustment
No



Power
AC Input Power
Universal:
100 to 120 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz
AC Power I/O
1x IEC Input
Power Consumption
350 W



Physical
Color
Black
Mounting
1 x 1.4″ / 36 mm Pole Socket (Bottom)
Handles
1x Each Side
Construction Material
Metal Grille, Polypropylene
Dimensions
24.9 x 15.2 x 14.6″ / 632.5 x 386.1 x 370.8 mm
Weight
31.7 lb / 14.4 kg



Packaging Info
Package Weight
37.27 lb
Box Dimensions (LxWxH)
28.3 x 18.4 x 18″
