Allen & Heath M-DX32-OUTPR-AX is a premium 8-channel line output module for DX32 expanders, optimized for dLive, Avantis, and SQ systems. It features next-generation 32-bit / 96kHz DACs, a fully balanced differential output stage, and ultra-low THD and noise. The module uses specially selected op-amps and passive components for maximum linearity, stereo depth, and transparency. PRIME circuitry is fully shielded for RF rejection and supports configurable DAC filter modes for latency and roll-off control. Ideal for critical monitoring, broadcast, and high-end PA applications.
FEATURES
- 8 × XLR line-level outputs
- 32-bit / 96kHz DACs with configurable filter modes
- Fully balanced differential output stage
- Ultra-low THD, noise, and crosstalk
- Full metal shielding for RF rejection
- Optimized for XCVI FPGA core
- Fits DX32 modular expander (slot-based)
- Compatible with dLive / Avantis / SQ systems
SPECIFICATIONS
| Model | M-DX32-OUTPR-AX |
| Brand | Allen & Heath |
| Series | PRIME / DX32 |
| Category | Output Module |
| Channels | 8 × Line Out |
| Conversion | 32-bit / 96kHz DAC |
| Design | Balanced Differential |
| Shielding | Full Metal RF Shield |
| Compatibility | DX32 / dLive / Avantis / SQ |
| Warranty | 1 Year Manufacturer Warranty |
| GTIN | 6938122242104 |
