The Ahuja TZA-2000 PA Mixer Amplifier is ideal for medium-sized installations such as in places of worship where two separate groups of speakers are needed to be connected. The user has a choice to connect both the zones to 100V (LMT) type speakers or 100V speakers to one zone and low impedance type speakers to the other zone. Both the zones can also be connected to low impedance type speakers.
Features
- ‘Stereo’ music operation, connecting of two separate groups of speakers, line inputs & outputs, preamplifier outputs, zone On/Off facility, DC fuses at rear panel, AC/DC operation has been provided.
- 6 Mic & 2 Aux Inputs.
- 100W+100W power output.
Specifications
| Power output: | 130W + 130W Max., 100W + 100W RMS at 10% THD, 90W + 90W RMS at 5% THD, 80W + 80W RMS at 2% THD |
| Input channel: |  Mono 6 × Mic 0.6mV/4.7k?, 2 × Aux 100mV/470k?, Stereo L/R 250mV/47k? |
| Frequency response: |  50-15,000Hz ±3dB |
| Signal to noise ratio: | Â 60dB |
| Power supply: |  AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery) |
| Power consumption: |  AC: 420VA DC: 6.5A |
| Dimensions: |  W500 × H140 × D340 mm |
| Weight: | 17.4 Kg |
