Audio professionals in need of a high-quality nearfield monitor will be impressed with the Adam Professional Audio A4V, a professional, 4″ 2-way studio monitor speaker that delivers rich, spacious, and enveloping sound, well suited for small studio spaces, short listening distances, and immersive multispeaker configurations.
A 110W RMS Class-D amplifier powers the 4″ Multilayer Mineral (MLM) woofer, while a 20W Class-AB amplifier drives the X-ART tweeter with HPS waveguide to provide an ultrawide frequency range (53 Hz to 42 kHz). The rotatable High-Frequency Propagation System (HPS) waveguide technology and onboard DSP allow you position the monitor either horizontally or vertically, while fine-tuning the speaker to your precise requirements.
Features
- 4″ Multilayer Mineral Woofer
- Rotatable X-ART Tweeter + HPS Waveguide
- 110W RMS Class-D Amp for Woofers
- 20W Class-AB Amp for X-ART Tweeter
- XLR and RCA Inputs
- Dual Bass Ports + 3 Voice Selections
- Room Adaptation: 4-Band Equalization
- Ethernet for A-Control DSP Software
- Integrated Sonarworks Room Correction
Specifications
Monitor Type | Active 2-Way |
Enclosure | Bass-Reflex, Shielded |
Power Rating | 130 W RMS |
Drivers | LF Driver: 1 x 4″ / 10.2 cm Composite Woofer with 1″ / 25.4 mm Voice Coil 1 x 1″ / 2.5 cm Ribbon Tweeter |
Amplification | 1 x LF Amplifier: Class-D Rated at 110 W RMS / 440 W Peak 1 x HF Amplifier: Class-AB Rated at 20 W RMS / 80 W Peak |
Frequency Response | 53 Hz to 42 kHz ± 6 dB |
Maximum Sound Pressure Level (SPL) | 100 dB (Peak) |
EQ | 1 x HF Shelf 1 x HF Notch/Peak 1 x Low-Mid Notch/Peak 1 x LF Shelf |
Filters | None |
Parametric EQ | None |
Crossover Frequency | 3 kHz |
Audio I/O | 1 x XLR Balanced Female Analog Input 1 x RCA Unbalanced Female Analog Input |
USB & Network I/O | 1 x RJ45 (Controller, Network, Remote) |
Maximum Sampling Rate | 96 kHz / 24-Bit |
AC Input Power | 100 to 240 VAC, 50/60 Hz |
Power Consumption | 300 W (Maximum) |
Mounting Points | None |
Dimensions (W x H x D) | 6.2 x 10.6 x 8.7″ / 15.8 x 26.8 x 22 cm |
Weight | 12.8 lb / 5.8 kg |
Package Weight | 17.05 lb |
Box Dimensions (LxWxH) | 16.2 x 15.7 x 11.9″ |
