Description

The AC-3 Acoustic Simulator from BOSS is a useful effect that turns your electric guitar into a virtual acoustic. Using the propriety COSM modeling technology, the AC-3 features Standard, Jumbo, Enhanced, and Piezo-equipped modes, as well as a built-in reverb effect. Separate outputs, one for guitar amps and one for PAs or recorders, allow for versatile configurations for the stage or studio. The AC-3 gives you an acoustic-like tone without having to carry a separate guitar.



Features

  • Acoustic Modeling in a Compact Pedal
  • Standard, Jumbo, Enhanced, & Piezo Modes
  • Top & Body Control Virtual Resonance
  • Built-In Reverb
  • Connect to Guitar Amp or PA
  • 9V Battery Included



Specifications

Nominal Input Level 20 dBu
Input Impedance 1 MOhm
Nominal Output Level -20 dBu
Output Impedance 1 kOhm
Recommended Load Impedance 10 kOhms or greater
Controls Pedal Switch, Mode Switch, Body Knob, Top Knob, Level Knob, Reverb Knob
Indicator LEDs Check indicator (Used for indication of Hold, and to check battery)
Connectors Input Jack, G.Out Jack, Line Out Jack, AC Adapter Jack (DC 9 V)
Power Supply DC 9 V: Dry battery (6F22/ 9 V), AC adapter (PSA Series: optional)
Current Draw 39 mA (DC 9 V)
Dimensions 2.8 x 4.9 x 2.2″ / 70.0 x 125.0 x 55.0 mm
Weight 1 lb (440 g)



Packaging Info
Package Weight 1.795 lb
Box Dimensions (LxWxH) 6 x 3.7 x 2.9″





Additional information
Brand

Boss
